Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

60W |
CHS60 | 19.05x12.7x23.36mm [0.75x0.5x0.92 inches] | Convection/Forced air |

80W |
CHS80 | 33.0x10.5x22.76mm [1.3x0.41x0.9 inches] | Convection/Forced air |

120W |
CHS120 | 33.0x10.5x22.86mm [1.3x0.41x0.9 inches] 33.5x12.7x23.36mm [1.32x0.5x0.92 inches] * (BasePlate Option) 36.5x12.7x26.5mm [1.44x0.5x1.04 inches] * (BasePlate and case Option) |
Convection/Forced air/Conduction |

200W |
CHS200 | 57.9x10.5x22.76mm [2.28x0.41x0.9 inches] 58.4x12.7x23.26mm [2.3x0.5x0.92 inches] * (BasePlate Option) |
Convection/Forced air/Conduction |

300W |
CHS300 | 58.4x11.0x22.86mm [2.3x0.43x0.9 inches] 58.9x12.7x23.3mm [2.32x0.5x0.92 inches] * (*BasePlate Option) 61.1X14.3X26.1 [2.41X0.56X1.03inches] ** (**Baseplate and case option) |
Convection/Forced air/Conduction |

380W |
CHS380 | 58.4x11.0x22.86mm [2.3x0.43x0.9 inches] 58.9x12.7x23.26mm [2.32x0.5x0.92 inches] * (BasePlate Option) |
Convection/Forced air/Conduction |

400W |
CHS400 | 58.4x9.5x36.8mm [2.3x0.37x1.45 inches] 58.9x12.7x37.3mm [2.32x0.5x1.47 inches] * (Baseplate option) 61.6x12.7x40.3mm [2.43x0.5x1.59 inches] * (Baseplate and case option) |
Convection/Forced air/Conduction |

500W |
CHS500 | 58.4x9.5x36.8mm [2.3x0.37x1.45 inches] 58.9x12.7x37.3mm [2.32x0.5x1.47 inches] * (BasePlate Option) |
Convection/Forced air/Conduction |

700W |
CHS700 | 58.4x10.5x36.8mm [2.3x0.41x1.45 inches] 58.9x12.7x37.3mm [2.32x0.5x1.47 inches] * (BasePlate Option) |
Convection/Forced air/Conduction |

Close

## CESseries

Rated Input: DC18 - 36V, DC36 - 76V *

Rated Output Wattage: 45 - 102W

*Input voltage range depends on model

Rated Output Wattage: 45 - 102W

*Input voltage range depends on model

Product Line-up

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

45 ～ 102W |
CES | 57.9x8.5x22.76mm [2.28x0.33x0.9 inches] | Convection/Forced air |

84 ～ 100W |
CES Type-P | 57.9x8.5x22.76mm [2.28x0.33x0.9 inches] 57.9x12.7x36.8mm [2.28x0.5x1.45 inches] |
Convection/Forced air/Conduction |

Close

## CQSseries

Rated Input: DC18 - 36V, DC36 - 76V *

Rated Output Wattage: 75 - 168W

*Input voltage range depends on model

Rated Output Wattage: 75 - 168W

*Input voltage range depends on model

Product Line-up

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

75 ～ 168W |
CQS | 57.9x8.5x36.8mm [2.28x0.33x1.45 inches] | Convection/Forced air |

Close

## CQHSseries

Rated Input: DC36 - 76V *

Rated Output Wattage: 250 - 350W

*Input voltage range depends on model

Rated Output Wattage: 250 - 350W

*Input voltage range depends on model

Product Line-up

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

250W |
CQHS250 | 57.9x10.5x22.76mm [2.28x0.41x0.9 inches] 58.4x12.7x23.26mm [2.3x0.5x0.92 inches]*(BasePlate Option) |
Convection/Forced air/Conduction |

300W |
CQHS300 | 57.9x12.7x36.8mm [2.28x0.5x1.45 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

350W |
CQHS350 | 57.9x12.7x36.8mm [2.28x0.5x1.45 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

## CBSseries

Rated Input: DC18 - 36V, DC36 - 76V *

Rated Output Wattage: 50 - 450W

*Input voltage range depends on model

Rated Output Wattage: 50 - 450W

*Input voltage range depends on model

Product Line-up

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

50W |
CBS50 | 57.9x12.7x61.0mm [2.28x0.5x2.4 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

100W |
CBS100 | 57.9x12.7x61.0mm [2.28x0.5x2.4 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

200W |
CBS200 | 57.9x12.7x61.0mm [2.28x0.5x2.4 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

350W |
CBS350 | 57.9x12.7x61.0mm [2.28x0.5x2.4 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

450W |
CBS450 | 57.9x12.7x61.0mm [2.28x0.5x2.4 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

## CDSseries

Rated Input: DC18 - 36V, DC36 - 76V *

Rated Output Wattage: 400 - 600W

*Input voltage range depends on model

Rated Output Wattage: 400 - 600W

*Input voltage range depends on model

Product Line-up

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

400W |
CDS400 | 61x12.7x116.8mm [2.4x0.5x4.6 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

500W |
CDS500 | 61x12.7x116.8mm [2.4x0.5x4.6 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

600W |
CDS600 | 61x12.7x116.8mm [2.4x0.5x4.6 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

50W |
DHS50A | 58.4x12.7x37.3mm [2.3x0.5x1.47 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

100W |
DHS100A | 58.4x12.7x37.3mm [2.3x0.5x1.47 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

200W |
DHS200A | 58.4x12.7x61.0mm [2.3x0.5x2.4 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

50W |
DHS50B | 58.4x12.7x37.3mm [2.3x0.5x1.47 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

100W |
DHS100B | 58.4x12.7x37.3mm [2.3x0.5x1.47 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

250W |
DHS250B | 58.4x12.7x61.0mm [2.3x0.5x2.4 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

50W |
SNDHS50A | 61.5x44.5x150mm [2.42x1.75x5.91 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

100W |
SNDHS100A | 61.5x44.5x150mm [2.42x1.75x5.91 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

200W |
SNDHS200A | 74.2x44.5x150mm [2.92x1.75x5.91 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

50W |
SNDHS50B | 61.5x44.5x127mm[2.42x1.75x5.0 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

100W |
SNDHS100B | 61.5x44.5x127mm[2.42x1.75x5.0 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

250W |
SNDHS250B | 74.2x44.5x127mm [2.92x1.75x5.0 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

## DBSseries

Rated Input: DC45 - 160V, DC66 - 160V, DC200 - 400V

Rated Output Wattage: 100 - 700W

Rated Output Wattage: 100 - 700W

Product Line-up

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

100W |
DBS100A | 61x12.7x116.8mm [2.4x0.5x4.6 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

150W |
DBS150A | 61x12.7x116.8mm [2.4x0.5x4.6 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

200W |
DBS200B | 61x12.7x116.8mm [2.4x0.5x4.6 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

400W |
DBS400B | 61x12.7x116.8mm [2.4x0.5x4.6 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

700W |
DBS700B | 61x12.7x116.8mm [2.4x0.5x4.6 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

400W |
SNDBS400B | 89x44.5x222mm [3.51x1.75x8.75 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

700W |
SNDBS700B | 89x44.5x222mm [3.51x1.75x8.75 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

## TUNSseries

Rated Input: AC85 - 264V

TUNS1200F AC85 ～ 305V

Rated Output Wattage: 50 - 1200W

TUNS1200F AC85 ～ 305V

Rated Output Wattage: 50 - 1200W

Product Line-up

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

50W |
TUNS50F | 58.4x12.7x37.3mm [2.3x0.5x1.47 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

100W |
TUNS100F | 58.4x12.7x61.0mm [2.3x0.5x2.4 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

300W |
TUNS300F | 117.3x12.7x61.5mm [4.62x0.5x2.42 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

500W |
TUNS500F | 117.3x12.7x61.5mm [4.62x0.5x2.42 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

700W |
TUNS700F | 117.3x12.7x61.5mm [4.62x0.5x2.42 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

700W |
TUNS700F-P | 117.3x12.7x61.5mm [4.62x0.5x2.42 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

1200W |
TUNS1200F | 117.3x12.7x86.8mm [4.62x0.5x3.42 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

150W |
TUXS150F | 76.2x28.5x50.8mm [3.0x1.12x2.0 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

200W |
TUXS200F | 76.2x28.5x50.8mm [3.0x1.12x2.0 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

50W |
SNTUNS50F | 50x36x150mm [1.97x1.42x5.91 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

100W |
SNTUNS100F | 74x37x150mm [2.91x1.46x5.91 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

300 ～ 500W |
DPG500 | 58.4x12.7x61mm [2.3x0.5x2.4 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

500 ～ 750W |
DPG750 | 58.4x12.7x61mm [2.3x0.5x2.4 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

500 ～ 750W |
SNDPG750 | 125x44.5x127mm [4.92x1.75x5.0 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

1000 ～ 1500W |
DPF1000 | 118.6x12.7x85mm [4.67x0.5x3.35 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close

Output Wattage | Model | Dimensions | Cooling Method |
---|---|---|---|

1000 ～ 1500W |
SNDPF1000 | 127x44.5x222mm [5.0x1.75x8.75 inches] | Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink) |

Close
